GGD fixed low-voltage distribution cabinet

The GGD type AC low-voltage distribution cabinet is suitable for power users such as energy, construction, power generation, substations, factories, mines, etc. The AC 50Hz, rated working voltage 380V, rated working current up to 1600A distribution system is used for power conversion, distribution, and control of electrical energy for power, lighting, and distribution equipment.
The GGD type AC low-voltage distribution cabinet is a new type of low-voltage distribution cabinet designed based on the principles of safety, economy, rationality, and reliability. The product has high breaking capacity, good dynamic and thermal stability, flexible electrical scheme, convenient combination, strong series and practicality, novel structure, and high protection level. It can be used as the best product for low-voltage switchgear.
The AC low-voltage distribution cabinet complies with GGD standards such as IEC60439-1 and GB7251.1.

Environmental conditions for use
1. The ambient air temperature should not be higher than+40 ℃ and not lower than -5 ℃. The average temperature for 24 hours shall not exceed+35 ℃.
2. Installation and use, the altitude of the usage location shall not exceed 2000M.
3. The relative humidity of the surrounding air does not exceed 50% at a maximum temperature of+40 ℃. Allow for higher relative humidity at lower temperatures. (For example, 90% at+20 ℃) should take into account the possibility of occasional condensation due to temperature changes.
4. The inclination of the equipment during installation with respect to the vertical plane shall not exceed 5 °.
5. During equipment installation, in places where there is no severe vibration or impact, as well as in places where electrical components are not sufficiently corroded.
6. Protection level: IP30.
